Triten T-34 is a highly engineered hardfacing alloy in the form of a tubular wire. When properly applied, it results in a high-chromium cast iron deposit with hard chromium carbides in a strong austenitic matrix. This is ideal for hardfacing components that are subject to severe abrasive wear and moderate impact.
Details:
- Metal-cored wire
- Open-arc or gas-shielded
- 2-3 layers can be applied
- Cutting with plasma torch is recommended
- Stress-relief cracking is normal and will occur
Applications:
- Hardfaced plate and pipe
- Mining and construction equipment
- Material transport conveyors, chutes, and ducting
- Scraper and grade blades
Properties
| C | Cr | Mo | Si | V | Hardness |
|---|---|---|---|---|---|
| ~ 5% | ~ 22% | ~ 3.5% | ~1% | ~ 1% | 64-68 HRC |
| C | ~ 5% |
| Cr | ~ 22% |
| Mo | ~ 3.5% |
| Si | ~ 1% |
| V | ~ 1% |
| Hardness | 64 – 68 HRC |
Parameters
| Wire Diameter | Amperage | Voltage | Stick-Out | Shielding Gas (if used) | ||||
|---|---|---|---|---|---|---|---|---|
| 1.6mm | 1/16″ | ~ 250 | 160 – 320 | ~ 26 | 24 – 30 | ~ 25mm | ~ 1″ | Ar / CO2 Mix or 100% CO2 |
| 2.4mm | 3/32″ | ~ 350 | 250 – 450 | ~ 28 | 26 – 32 | ~30mm | ~1-1/4″ | |
| 2.8mm | 7/64″ | ~ 425 | 350 – 550 | ~ 29 | 26 – 32 | ~ 30mm | ~1-1/4″ | |
| Wire Diameter | 1.6mm | 1/16″ |
| 2.4mm | 3/32″ | |
| 2.8mm | 7/64″ | |
| Amperage | ~ 250 | 160 – 320 |
| ~ 350 | 250 – 450 | |
| ~ 425 | 350 – 550 | |
| Voltage | ~ 26 | 24 – 30 |
| ~ 28 | 26 – 32 | |
| ~ 29 | 26 – 32 | |
| Stick-Out | ~ 25mm | ~ 1″ |
| ~30mm | ~1-1/4″ | |
| ~ 30mm | ~1-1/4″ | |
| Shielding Gas (if used) | Ar / CO2 Mix or 100% CO2 | |
Triten T-34
Want to Know More?
For more information download our Product Data Sheet.
